About TOA TS-910 Central Unit Integrated Conference System
The TOA TS-910 Central Unit Integrated Conference System is designed to manage wired and compatible infrared conference units in professional meeting environments. It supports up to 192 conference units, includes a built-in Feedback Suppressor (FBS), and provides audio connections for recording, external equipment, and simultaneous base-language and translation-language communication.
Specification
| Specification | Details |
|---|---|
| Brand | TOA |
| Model | TS-910 |
| Product Type | Conference System Central Unit |
| System Type | Integrated Conference System |
| Power Source | 100–240V AC, 50/60Hz via supplied AC adapter |
| Power Consumption | 72W |
| Maximum Current Consumption | 3A DC |
| Compatible Conference Units | TS-901, TS-902, TS-911, TS-912, TS-801, TS-802, depending on configuration |
| Maximum Conference Unit Capacity | Up to 192 units |
| Expansion Unit Connections | Up to 4 units directly |
| Expansion with Distributor | Up to 8 expansion units |
| Expansion Interface | BNC jack |
| Microphone Inputs | 2 |
| AUX Inputs | 3 |
| Base Language Input | Supported |
| Translation Language Input | Supported |
| Line Output | -20dB, 10kΩ, unbalanced |
| Recording Output | Phone jack and RCA pin jack |
| Headphone Output | 3.5mm mini jack |
| External Equalizer | Input and output connections |
| Feedback Suppression | Built-in FBS |
| Simultaneous Speaker Selection | 1, 2, 3, or 4 |
| Automatic Microphone-Off | Timeout ON/OFF |
| Speech Priority | First-in-first-out, last-in-first-out, and fixed-priority modes |
| Voting Function | Supported with compatible system components |
| External PC Control | D-sub 9-pin or USB-B, selectable |
| Status Indicators | Voting, audio channels, data reception, external control, and system status |
| Rack Mounting | Optional MB-TS900 bracket |
| Operating Temperature | 0°C to +40°C |
| Operating Humidity | 90% RH or less, non-condensing |
| Dimensions | 359 × 118.8 × 138.2mm |
| Weight | 2.8kg |
| Finish | Gray metallic semi-gloss panel |
| Included Accessory | AC adapter and applicable power cord |
TOA TS-910 Central Unit Integrated Conference System in BD
The TOA TS-910 Central Unit Integrated Conference System is suitable for professional conference installations in Bangladesh, including boardrooms, government meeting rooms, conference halls, and institutional facilities. Its expandable architecture, feedback suppression, PC control, and recording connections support organized communication for larger meetings. Availability may vary depending on current stock and market conditions.
User Experience of TOA TS-910 Central Unit Integrated Conference System
The TS-910 central unit helps manage microphone activity and audio distribution across a conference system. Its selectable speaker limits and speech-priority settings support orderly discussions, while the built-in Feedback Suppressor helps reduce unwanted acoustic feedback. Separate base-language and translation-language audio paths make it suitable for meetings that require language interpretation. Recording outputs also allow conference audio to be captured using compatible equipment.
Why Choose this TOA TS-910 Central Unit Integrated Conference System?
This central unit is designed for professional conference environments that require centralized control and expansion flexibility. It supports up to 192 compatible conference units, offers PC-based external control, and includes voting-related system functions. Its audio inputs, recording connections, and feedback suppression capabilities make it a practical component for structured meetings and institutional conference installations.
Key Features
- Central control for compatible conference units
- Supports up to 192 conference units per system
- Compatible wired and infrared configurations, subject to system setup
- Built-in Feedback Suppressor (FBS)
- Separate base-language and translation-language audio channels
- Microphone and AUX inputs
- Recording outputs for compatible recording equipment
- Selectable simultaneous speaker limits
- Adjustable microphone timeout settings
- Configurable speech-priority modes
- Voting-related functions with compatible units and software
- External PC control through supported interfaces
- Expansion unit connections
- Optional rack mounting with MB-TS900
Why Buy From TOA PA System Bangladesh?
The TOA PA System Bangladesh offers professional audio and conference solutions for corporate, commercial, and institutional environments. The TS-910 provides centralized conference management, flexible audio connections, and expansion capabilities for organized meeting communication.
- TOA professional conference system product range
- Suitable for corporate and institutional installations
- Centralized microphone and discussion management
- Recording and external audio connection options
- Expandable system architecture
- Suitable for professional conference room projects
Where It Can Be Used?
- Corporate boardrooms
- Government meeting rooms
- Conference halls
- Parliament and council chambers
- Hotels and multipurpose halls
- Educational institutions
- Training and seminar rooms
- Institutional meeting facilities
- Large committee rooms
- Meetings requiring language interpretation
What is the Price of Toa TS-910 Central Unit Integrated Conference System in BD?
The latest price of Toa TS-910 Central Unit Integrated Conference System in Bangladesh depends on product availability and current market conditions. For the latest pricing information, stock details, and purchasing assistance, please contact TOA PA System Bangladesh via WhatsApp or email.
